CH

CH-range

The best-in-class system design is flexible enough to meet almost any requirement, both technically and commercially. The range is adapted for safe or hazardous areas. When the amounts of solids in the feed are low, we normally recommend an intermittent discharging centrifuge solution (PX-type). The automatic solids discharge technology helps minimize product loss.

産業用アプリケーションまたは処理量の少ないパイロットプラント用のスキッドマウント型ディスク型遠心分離システムです。CH 20は、少量の固形物を含む対象液の、液体と微細な固体を分離します。

• 100 l/hから4 m3/hまで、用途に応じて選択可能

詳しく見る

中程度の処理能力を持つ産業用アプリケーション向けのモジュール式ディスク型遠心分離システムです。CH 300 は、少量の固形物を含む対象液の、液体と細かい固形物を分離します。

• 用途に応じて、1m3/hから30m3/hまで

詳しく見る

中程度の処理能力を持つ産業用アプリケーション向けのモジュール式ディスク型遠心分離システムです。CH 600 は、少量の固形物を含む対象液の、液体と微細な固体を分離します。

• 1 m3/hから60 m3/hまで、用途に応じて選択可能

詳しく見る

Modularized disc stack separation system for industrial applications with medium throughput. CH 700 separates liquids and fine solids in streams with small amounts of solids.

• From 1 – 70 m3/h per hour depending on application

• No shear acceleration of feed ensures product integrity and exceptional yield

Read more

Modularized disc stack separation system for industrial applications with medium throughput. CH 900 separates liquids and fine solids in streams with small amounts of solids.

• From 1 m3/h to 90 m3/h depending on application

• No shear acceleration of feed ensures product integrity and exceptional yield

• Completely enclosed operation

Read more

The Alfa Laval CH 900 centrifugal separator takes separation to a new level thanks to the innovative design of its flow path. The center-to-center principle ensures gentle acceleration into the high G-force separation environment inside the disc stacks. With this flow path design, Alfa Laval CH 900 uses up to 40% less power than conventional centrifugal separators.

The central bottom feed creates a liquid-filled, low-shear environment. The gentle acceleration of the feed keeps the feed droplets or particles intact. This results in superior separation performance, especially when handling emulsions or shear-sensitive particles.

The gentle flow conditions and short settling distances help ensure a low hold-up volume and keep the footprint to a minimum. The center-to-center flow design provides a fully enclosed, gas-tight handling of the process liquid.

CHX-range

The best-in-class system design is flexible enough to meet almost any requirement, both technically and commercially. The range is adapted for safe or hazardous areas. For processes containing high amounts of solids, we recommend a nozzle centrifuge (X-type) which enables continuous discharging. There are multiple types of nozzle separator to suit different applications. The nozzle type separator gives you the flexibility to handle high volumes of solids in the feed, fluctuating amounts of solids as well as high flow rates. Nozzles can be replaced from the outside.

Modularized disc stack separation system for industrial production with high amount of solids

• 5 – 50 m3/h depending on application

Modularized disc stack separation system for industrial production with high amount of solids

• 10 – 50 m3/h depending on application

Modularized disc stack separation system for industrial production with high amount of solids

• 10 – 200 m3/h depending on application

• Increased erosion & corrosion resistance for extra tough applications

CHB-range

The best-in-class system design is flexible enough to meet almost any requirement, both technically and commercially. The range is adapted for safe or hazardous areas. CHB is a non-discharging solid bowl (B-type) centrifuge solution for liquid/liquid separation applications where there are only small traces of solids in the feed. Any solids that enter the bowl will remain in the bowl until the unit is taken out of service and the solids are manually removed.

Modularized disc stack separation system for industrial applications with low amounts of solids

• 5 – 15 m3/h depending on application

Proven technology for biobased processes

The use of biobased processes in the Chemicals, Pulp & Paper and Renewable/Recycling industries is growing. Disc stack separators are since long a key technology in, for example, industrial fermentation and algae processes in food and pharma industries. Our separation equipment and know-how are invaluable for these new process industries.

Learn about the inner workings of the center-to-center function which provides a hermetic design and an enclosed process. See how it provides gentle product handling and maximum product quality

Efficient separation of biomass with Alfa Laval hermetic technology.

Manufacturing world-leading separators

Alfa Laval delivers premium products for energy, food, water, biotech and pharma applications across the world based on more than a century of experience. Here’s one example from our Eskilstuna factory in Sweden.
